Application:

Suitable for large iron and steel plate lifting and moving.

Feature:

• Battery type Permanent magnet electronic control structure design, with Neodymium (NdFeB).
  No electric power supply required to keep magnetic chuck ON and provides maximized safety in case of power failure.
• Low-voltage safety warning system, can detect the lithium battery power through the screen at any time.
• With explosion proof Lithium battery, the charger can be setting 110V~220V.
  EPLM (B) can be used for operating 160 cycles after the battery is fully charged.
  EPLM (D) can be used for operating 100 cycles after the battery is fully charged.
• The magnetism is divided into 5 levels, it can be adjusted the best magnetic force level for different workpieces.
• Modular design can be freely expanded the output port, and the number of EPLM (B) Lifters are according to the application.
• The numbers of EPLM (B) can be operated by wireless remote control the maximum can be 10 pcs EPLM (B) Lifter. Under unobstructed environment, the wireless remote control distance can be 20 meters.
• Customization：Replaceable induction block will be alternative option according to different workpiece sizes or shapes to meet the various applications requirements.
• Proximity sensor device: When the hoisting and lifting is started the wireless remote control device can't carry out any operation to prevent potential risk of workpiece dropping caused by mistouch the button.
